Network Analyser

Network Analyser

CAT NO: DIDACTICECE-LAB-0133

Network Analyser Description and Tender Specification:

Network Analyser.

PROTOCOL ANALYZER
This software is designed to analyze and study the used
Communication protocols. In detail, it carries out the real time
monitoring, analysis, and decoding of protocol on Ethernet
networks.
TECHNICAL SPECIFICATION:
• It can catch, display and decode the network traffi c in real
time
• Diagnostics of troubles via network traffi c analysis
• Statistics in real time: talker, use of band, distribution of
protocols, network activity and VLAN analysis
• Packing fi lter
• Trigger and alarm functions
• LAN 10/100/1000 Ethernet compatibility
• Trending and network Reporting
• Analysis, stacking and monitoring of VLAN network
• It will be installed in 1 PC (not included)
RACK SERVER
This optional unit ensures all network services (www, ftp,
TECHNICAL SPECIFICATION:
• Processor: Dual-Core Intel, 1.6 GHz
• Memory: 2 GB
• Internal hard disk drive: 500 GB Non Hot Plug SATA
• 2 Copper Gigabit Adapters: 10/100/1000 Mbps on RJ45
connector
• Dimensions: 1U, Rack 19”
• Mechanical installation: it will be inserted in Wiring &
Electronics Panel of Lan Technology mod. LB3/EV
• Preinstalled: NOS Microsoft Windows Server and Exchange
Server
• Preinstalled and confi gured functions: Server E-mail, FTP
services, resource sharing and access to Web Page
• Included peripherals: LCD monitor, keyboard and mouse

TESTER FOR CABLES
This measuring optional instrument, provided with LCD display
and various accessories, is designed for wiring assessment.

TECHNICAL SPECIFICATION:
• It displays:
- Cable lenght: to the termination, short-circuit and open
circuit
- Cable mapping
- cable ID
- Distance to faults
• Support compatibility: RJ11, RJ45 and coaxial
• Analog and digital tone generation used to test a cable.
• Detection of VDV, Ethernet 10/100/1000 (802.3), POTS and
PoE (802.3af) services
• Case of hard Rubber
• Backlit king-size display
TECHNICAL SPECIFICATION:
• TCP/UDP traffi c generator for LAN on IP
• 2 PCs can be used for max 32 IP simultaneous connections:
PC TX (16 ) e PC RX (16 ).
• Operation in manual TX mode: it is possible to select the
data source of the traffi c generator, for each link, and to
confi gure the size of packets together with their delay.
• Operation in automatic TX mode: it is possible to select a
mathematical law for the generated links (max.16), the
starting time and then a second law can be selected for the
volume of data to be sent.
• Loading, debugging and stressing test for applications and
equipment.
• Measurement of RTT (Round Trip Time) for Performance
analysis, statistics on the IP traffi c
• Compatible with Windows O.S.: 2000, XP, Vista and Windows
Server 2003
• It will be installed on 2 PCs (not included)
NETWORK TESTING SOFTWARE
This optional Software is designed for TCP/UDP traffi c
generation, load testing, debugging, stress on applications and
equipment, performance analysis and traffi c statistics.
NETWORK ANALYSIS SOFTWARE
mod. LB3-N/EV
It is an optional software that enables the identifi cation of
the network equipment together with the typology and the IP
address, the drawing and the network display.
TECHNICAL SPECIFICATION:
• Useful tool for:
- tracing the devices connected with the network
- detecting the topology and IP address
- tracing the network lay-out
- repairing link faults and controlling alarms
• This software package is the perfect tool for servicing and
monitoring QoS
• Route mapping function between the PC (as analyzer) and
a network device via its IP. It will trace a graph or table
complete with transit time.
• Network Mapping function of a network or of a network
segment over IP, IPX or MSFT. It will monitor the answer time
and performance.
• It will be installed on 1 PC (not included)
COPPER TOOL KIT
This optional set includes all the necessary devices and
accessories for carrying out the RJ45 connector termination
and wiring a patching panel.

NETWORK TESTING SOFTWARE
This optional Software is designed for TCP/UDP traffi c
generation, load testing, debugging, stress on applications and
equipment, performance analysis and traffi c statistics
TECHNICAL SPECIFICATION:
• TCP/UDP traffi c generator for LAN on IP
• 2 PCs can be used for max 32 IP simultaneous connections:
PC TX (16 ) e PC RX (16 ).
• Operation in manual TX mode: it is possible to select the
data source of the traffi c generator, for each link, and to
confi gure the size of packets together with their delay.
• Operation in automatic TX mode: it is possible to select a
mathematical law for the generated links (max.16), the
starting time and then a second law can be selected for the
volume of data to be sent.
• Loading, debugging and stressing test for applications and
equipment.
• Measurement of RTT (Round Trip Time) for Performance
analysis, statistics on the IP traffi c
• Compatible with Windows O.S.: 2000, XP, Vista and Windows
Server 2003
• It will be installed on 2 PCs (not included)
.
NETWORK ANALYSIS SOFTWARE
It is an optional software that enables the identifi cation of
the network equipment together with the typology and the IP
address, the drawing and the network display.
TECHNICAL

SPECIFICATION:
• Useful tool for:
- tracing the devices connected with the network
- detecting the topology and IP address
- tracing the network lay-out
- repairing link faults and controlling alarms
• This software package is the perfect tool for servicing and
monitoring QoS
• Route mapping function between the PC (as analyzer) and
a network device via its IP. It will trace a graph or table
complete with transit time.
• Network Mapping function of a network or of a network
segment over IP, IPX or MSFT. It will monitor the answer time
and performance.
• It will be installed on 1 PC (included)
