CAT NO: DIDACTICNLE-Export-112001
Pullout Test Apparatus.
Pullout Test Apparatus
500 kN (50 Tonnes)
Consists of following:
Hydraulic Centre Hole Jack
500kN (50 Tonnes) capacity with 54mm Centre Hole, 150 mm Ram Travel, DoubleActing
Hand Operated, two stage Pump
Thermoplastic Hose
6m long with pair of quick couplings
Load Gauge
150mm dia, 500kN x 5KN
Reaction Frame
500kN capacity with 90mm hole at base
High Strength Test Rod
40mm dia
High Strength Coupling
Having RH thread to suit Test Rod on one end and LH thread to suit 20mm dia Rockbolt on the other end.
High Strength Coupling
Having RH thread to suit Test Rod on one end and LH to suit 25 mm dia Rockbolt on the other end.
High Strength Coupling
Having RH thread to suit Test Rod on one end and LH to suit 30 mm dia Rockbolt on the other end.
High Strength Coupling,
Having RH thread to suit Test Rod on one end and LH to suit 32 mm dia Rockbolt on the other end.
Dial Gauge
0.01 x 25 mm
Pullout Test Apparatus
250 kN (25 tonnes)
Hydraulic Centre Hole Jack
250 kN (25 Tonnes) capacity
Load Gauge
150 mm dia. 250 kN x 2.5 kN
Reaction Frame
250 kN capacity with 90 mm hole at base
