RESISTANCE WELDING EQUIPMENT

RESISTANCE WELDING EQUIPMENT

CAT NO: DIDACTICNULK2- -0113

RESISTANCE WELDING EQUIPMENT Description and Tender Specification:

RESISTANCE WELDING EQUIPMENT.

·           Rated power @ 50 % Duty cycle: 75kVA

·           Secondary voltage: 6.5, 9

·           Welding current max: 15KA

·           Control type: Secondary feedback constant current control

·           Time setting least count: 20 msec

·           Throat depth: 250 – 300mm

·           Arm gap (max): 300mm

·           Electrode force (min – max): 150 to 470kg

·           Free Air consumption (@1 bar ) for 100 spots  and
25mm stroke: 250 litres

·           Strokes per second max at no weld: 6

·           Cooling water pressure: 2 kg/cm sq

·           Cooling water flow rate min: 10



Welding Capacity

·           Sheet metal CRCA mm

·           Sheet metal HR mm

·           Sheet Metal SS mm

Projection Nut Welding, mm
