Microscope

Microscope

CAT NO: DIDACTICNEL0693

Microscope Description and Tender Specification:

Microscope.
Microscope TRINOCULAR PHASE Lx400 Stand Single mold sturdy stand with anti rust materials. Extended base for better stability Eyepiece Focusable widefield eyepiece 10x/20mm with foldable eye guard Objectives RP series infinity corrected DIN Plan Achromatic objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil), anti fungus Condenser Sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue day light filter. Rack and pinion movements on stainless steel guides Illumination Halogen 6V-20W/30W or LED (in-built rechargeable battery) illumination with variable illumination control. Up to 2,000 hours of Halogen lamp life and 100, 000 hours of LED life Optional accessories Zernike Phase contrast kit with RP series Phase objectives 10x/20x/40x/100x, Dark field kit, Simple Polarizer/Analyzer, Dual View attachment, Fluorescence attachment; Video adapter Viewing Bodies Siedentopf Binocular and Trinocular head, 30° inclined, 360° rotatable, Inter pupillary distance 48 - 75mm Nosepiece Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip Mechanical stage Rackless X axis, double plate stage size 200 x 160mm, X/Y travel range 78mm x 54mm. Low drive right hand movement controls. Hard coated surface for scratch resistance. Double specimen holder Focusing Coaxial coarse and fine focusing on ball drive system for smooth operation Electrical Universal input 100V - 240V AC, 50/60Hz
