Charrpy Impact Testing Machines

Charrpy Impact Testing Machines

CAT NO: DIDACTICNLE-Export-202085

Charrpy Impact Testing Machines Description and Tender Specification:

Charrpy Impact Testing Machines.
Charrpy impact testing machines 1. Microcomputer control, electric rising pendulum, impact , results are measured calculated by microcomputers and displayed digitally and printed out, having high operation efficiency, high testing accuracy. the energy which is remained after the specimen is impacted broken can automatically rise the pendulum for the next testing, simple operate and has high working efficient, the materials impact absorbed energy, impact elasticity and pre-rising angle of pendulum and average   value of test can be calculated and displayed, The test data and average value of the time can be printed. 2. The principle machine of the testing machine has single column structure, Cantilever type pendulum hanging mode, the pendulum body is U-shaped. 3. The impact cutter is installed and fixed by screws and is convenient and easy to replaced. 4. The specimen is supported via simply by supported beam 5. Safety guard pin is arranged on the principle machine which is also provided with safety guard net. 6. The testing machine is controlled in a semi-automatic way, electric control is realized for pendulum rising, pendulum hanging, impacting and pendulum placing, The energy which is remained after the specimen is broken can automatically rise the pendulum for the next testing, thus, the testing machine is suitable to be used in laboratories which make consecutive impact tests or the metallurgy and machine manufacturing sectors which are involved with a large of impact tests. 7. The testing machine is in conformity with the international standard ISO 148 and ASTM E23 Technical Parameters: 1. Impact energy: 300J, 150J (500J, 250J) 2. Angel of the Pendulum raises in advanceï¼ï¿½ 150° 3. Impact speedï¼ï¿½5.2m/s 4. Distance from the centre of hammer to impact pointï¼ï¿½750mm 5. Span of sample branch seatï¼ï¿½40mm 6. Radius of arc circle of sample branch seatï¼ï¿½ R1-1.5mm 7. Arc circle radius of impact knifeï¼ï¿½ R2-2.5mm R8mm 8. Impact knife thickness: 16mm 9. Size of sampleï¼ï¿½ 10×10×55mm 10. Size of outlineï¼ï¿½2124 × 600 ×1340mm 11. Net weight: 450Kg 12. Powerï¼ï¿½Three Phases 380V, 50Hz
