Embedded Project Board For 8051 Family (Pic Microcontroller Trainers)

Embedded Project Board For 8051 Family (Pic Microcontroller Trainers)

CAT NO: DIDACTICNEB011

Embedded Project Board For 8051 Family (Pic Microcontroller Trainers) Description and Tender Specification:

Embedded Project Board For 8051 Family (Pic Microcontroller Trainers).
EMBEDDED PROJECT BOARD FOR 8051 FAMILY (PIC MICROCONTROLLER TRAINERS) CPU: Philips 89C51RD2 or 89S61X2 series On-board Internal Memory 64K Internal Program Memory 1K Internal Data Memory  Speed up to 20 MHz with 6-clock cycles per machine cycle (40 MHz equivalent performance); up to 33 MHz with 12 clocks per machine cycle Four interrupt priority levels Seven interrupt sources Four 8-bit I/O ports available in 26 pin FRC polarized connector On-Board ISP(in system Programming) facility  Windows Based ISP Programming Software Two 26pin FRC cable & one 40 Pin FRC cable  On-Board REAL TIME CLOCK using RTC6242  On-Board 64K External DATA Memory using 2 nos. of 62256  I2C Serial EPROM using 93c46   On-Board Parallel Port brought out at 25 pin D-Type connector.  All ICS are mounted on IC Sockets. Made of Bare board Tested Glass Epoxy SMOBC PCB.   In-Built Power Supply of +5V/1A, ±12V/150mA Wooden enclosures of Light weight Wood. Users Manual with sample programs ALL IC-XX SERIES INTERFACING CARDS ARE COMPATIBLE WITH, CAD/CAM LABORATORY EQUIPMENTS, educational cnc milling machines manufacturers, educational cnc LATHE machines manufacturers, Strength of Material Testing equipment supplier, mechanical engineering laboratory equipments suppliers, soil, bitumen, concrete testing, civil engineering laboratory equipments suppliers, garage workshop machinery  manufacturers
