Function Generator

Function Generator

CAT NO: DIDACTICNTE-11-12-0155

Function Generator Description and Tender Specification:

Function Generator.
THIS is an extremely versatile 2Mhz Function Generator. It has a wide frequency range with LED display for frequency. The output amplitude can be varied upto 20 Vpp (open circuit) and can be attenuated to -60 dB. All outputs are short-circuit proof. TTL / CMOS out is available for Digital Lab experiments. And also it has a 30 MHz Frequency Counter in-built with Function Generator. Additional features indicating its high quality include constant amplitude flatness and low distortion factor of signals. It is a new laboratory standard offering low cost solution to all your needs.
FEATURES
2MHz Function generator
Output waveform Sine, Triangle, Square, Ramp, Pulse
Voltage Control Frequency (VCF) capability
TTL/CMOS and OUTPUT synchronous output Less than distortion at 10hz-100khz
Less than 0.5dB frequency response at 0.1 Hz~100kHz
1 1Hz~30MHz frequency counter
AM/FM (Optional, model no. with suffix "A")
Specifications
2MHz Function generator
•    Frequency range    : 0.1Hz - 2MHz
•    Display    : 6 digit LED display
•    Output waveforms : Sine, Triangle, Square, ± Pulse, ± Ramp
•    Output Impedance : 50± 10%
•    Output Amplitude : 20Vp-p(open circuit) ,10Vp-p(with 50 load)
•    DC Offset : 0 to ± 1OV continuously adjustable
•    Symmetry Range    : 90:10 - 10:90
•    Rising Edge of Square :
•    Distortion : <1% (at lOHz-100KHz)
Frequen
