Heat Transfer in a Refrigeration Systems

Heat Transfer in a Refrigeration Systems

CAT NO: DIDACTICNEX080

Heat Transfer in a Refrigeration Systems Description and Tender Specification:

Heat Transfer in a Refrigeration Systems.
Heat transfer in a refrigeration systems Model of a refrigeration system with closed water circuit that is used as a cooling load 1 x w x h: 1000x600x1050mm, 100kg Hot water circuit with tank, heater, pump and temperature controller Hermetic piston compressor Coaxial evaporator and condenser Heater 300W Sight glass in the refrigerant circuit Instrumentation: bimetallic thermometers and rota meters Compressor: power consumption: 150W at -10°C, refrigerating capacity: 280W at 0/32°C Coaxial tube heat exchanger: capacity: 2kW at 45°C condensing temperature, DT=7K Circulating pump, 3 stages: 30-45-60W Max. Flow rate: 2.9m3/h, Max. head: 4m Heater 300 W Insulated water tank: 4.51tr Measuring ranges: temperature: 4x 0...60°C - flow rate: 2x 0...331tr/h Mobile refrigeration unit with normal cooling stage and deep-freezing stage Selection of cooling stage via solenoid valves Individual and parallel operation of the cooling stages possible Cooling stages: insulated chambers with air-cooled evaporators Semi-hermetic piston compressor, air-cooled condenser Compressor: - power consumption: approx. 13TOW, CAD/CAM LABORATORY EQUIPMENTS, educational cnc milling machines manufacturers, educational cnc LATHE machines manufacturers, Strength of Material Testing equipment supplier, mechanical engineering laboratory equipments suppliers, soil, bitumen, concrete testing, civil engineering laboratory equipments suppliers
