Infinity Refractive Index Detector

Infinity Refractive Index Detector

CAT NO: DIDACTICNEL0069

Infinity Refractive Index Detector Description and Tender Specification:

Infinity Refractive Index Detector.
infinity Refractive index Detector Includes 8uL flow cell and LAN interface and twisted pair cable. Detection type: Deflection method Short-term noise: ± 2.5 x 10-9 RIU Drift: < 200 x 10-9 RIU/h Refractive index range: 1.00-1.75, calibrated Flow cell: 8 µL,5 bar pressure maximum Temperature control: Ambient + 50C to 550C pH range: 2.3-9.5 Time programmable: Polarity, peak width Zero adjust: Automatic zero Valves: Automatic purge and automatic solvent recycle Data rate: UP to 37 Hz Analog output: Recorder/integrator: 100mV or 1V, with offset adjustment, RIV range selectable. Communications: Local Area Network (LAN), Control Area Network (CAN), RS-232, APG remote, remote ready, start and shutdown signa Safety and maintenance: Extensive diagnostics, error detection and display leak detection, safe leak handling, leak output signal for shutdown of pumping system, low voltage in major maintenance areas. GLP features: Early maintenance feedback (EMF) for continuous tracking of instrument usage with user-settable limited (purge interval) and feedback messages.  Electronic records of maintenance and errors, automated OQ/PV procedures.
