CAT NO: DIDACTICECE-LAB-0164
Module for Electrical Measurements on Electrical Modules with 24
interchangeable module to carry out programs
on general electrical measurements and
machines experiments with a wide range of
instruments and controls.
TECHNICAL SPECIFICATIONS
The set of modules to carry out the programs on general
electrical measurements and measurements on electrical
machines consists of:
2 Modules type AZ-50
1 Three-pole drum switch
3 Modules type AZ-60
1 Moving iron voltmeter 250-500 V – cl. 1.5
3 Modules type AZ-61
1 Moving iron ammeter 2-4 A – cl. 1.5
2 Modules type AZ-62
2 Electrodynamometer wattmeter 2-4 A 250 – 500 V – cl. 1.5
1 Module type AZ-63
1 Resistor box (artificial star point) for wattmeter
1 Module type AZ-64
1 Vibrating reed frequency-meter 48:62 Hz 250-500 V – cl. 1.5
1 Module type AZ-65
1 Galvanometer (central zero microammeter) 50-0-50 /μA –
cl. 1.5
1 Module type AZ-66
1 Electrodynamic three-phase power factor meter 2-4 A
250-500 V – scale 0.5-1-0.5 – cl. 2
1 Module type AZ-67
1 Lamp sequencescope
1 Module type AZ-68
1 Synchronization device for parallel of generators or threephase
lines
1 Module type AZ-69
1 Electrodynamic single-phase power factor meter 250 V
2-4A – scale 0.4-1-0.4 – cl.2
1 Module type AZ-70
1 Moving iron milliammeter 250 – 500 mA – cl.1,5
1 Module type AZ-71
1 Moving iron voltmeter 25-50 V – cl. 1.5
1 Module type AZ-72
1 Moving iron ammeter 10-20A – cl.1.5
1 Module type AZ-73
1 Tachometer voltmeter 240VCC – scale: 1000/2000/4000
rpm cl. 1.5
Supplied accessories
Set of 25 cables with safety pins Ø 4 mm
