CAT NO: DIDACTICFM Lab Equipments0007
Pipes in Parallel.
Pipes in Parallel
The setup is designed to study the pipes in parallel of same diameter.
up consists of a set of 2 pipe test sections, supply tank, measuring
tank and pump for closed loop water circulation
A set of valves is
provided to conduct the experiment. The test sections are connected to
differential manometer through Piezometer and gang box.
The flow rate of water is measured using measuring tank and stop watch provided
To study the pipes in parallel.
Electric supply 0.5 kW, 220V AC, Single Phase
Water supply Tap water connection ” BSP Distilled water @ 60 liters (optional)
Floor Area with Drain facility
