Single-Phase PWM Inverter Training Module

Single-Phase PWM Inverter Training Module

CAT NO: DIDACTICNMT0074

Single-Phase PWM Inverter Training Module Description and Tender Specification:

Single-Phase PWM Inverter Training Module.
Single-Phase PWM Inverter Training Module
Terminals for the connections and measurements;
MOSFET: 2 MOS channels N and 2 MOS channels P; Output voltage: sine 24 Vac / 1 A; Output voltage frequency: 50 Hz
Switching frequency of the PWM generator: 20 kHz; External unit mod. TY23A/EV for housing the output transformer, the filters and the R-L-C loads.
DIM.: 386x372x50 mm;
Power Supply: +30 Vdc / 2 A;
Required Instruments:  Oscilloscope; Multimeter;
