Transmission Line Simulator

Transmission Line Simulator

CAT NO: DIDACTICNLE-Export-202462

Transmission Line Simulator Description and Tender Specification:

Transmission Line Simulator.
transmission line simulator Specifications: •    Transmission Line is the key learning concept for Electrical Engineers.Transmission Line Training System is exclusively designed to deliver the learning aspects of the electrical transmission line. Digital display is provided for easy measurement of Voltage, Current, Power, Power Factor, etc. These parameters help students to learn the characteristics of transmission line and calculations of the ABCD, H, Z parameters. Students can perform various experiments like short, medium and long transmission line and their behavior. Also one of the important experiment which can be performed with this training system is Ferranti Effect Technical specification Multifunction digital meters for  measurement }Simultaneous display of sending and receiving parameters }Highly sensitive to change in reading for better controlling } }Inbuilt Single Phase Variac to regulate supply } Equipped with fixed R, L and C Load } Facility to configure Short, Medium and Long Transmission Line using multiple value of R, L and C } Designed by considering all the safety standards } Diagrammatic representation for the ease of connections } Scope of learining To study Short Circuit, Medium, Long Transmission Line Determine the ABCD, H, Z and Image parameters of Short Transmission ?Line Determine the ABCD, H, Z and Image parameters of Medium Transmission Line For T network ?For ð network Determine the ABCD, H, Z and Image parameters for Long Transmission ?Line Measure the receiving end voltage of each line under no load or lightly ?load condition to understand Ferranti effect Understand the performance of transmission line under different loads Technical specifications Mains Supply : 230V ±10%, 50Hz  Single Phase Variac Input : 230V Output : 0-270V Current : 0-2A Display Measurement Voltage :á25V Current :á0.2A Active Power :á20W [2000W Reactive Power :á20VAR [2000VAR  Apparent Power :á20VA [2000VA Loads Resistor : 700Ù/ 100W Inductor : 800mH/ 0. 5A Capacitor : 12.5µF/ 450V, CAD/CAM LABORATORY EQUIPMENTS, educational cnc milling machines manufacturers, educational cnc LATHE machines manufacturers, Strength of Material Testing equipment supplier, mechanical engineering laboratory equipments suppliers, soil, bitumen, concrete testing, civil engineering laboratory equipments suppliers
