CAT NO: DIDACTICNLE-Export-205103
EXERCISES AND PRACTICAL POSSIBILITIES
Some Practical Possibilities of the Unit:
1.Measurement of overall efficiency and estimation of impeller power efficiency.
2.Measurement of performance at constant speeds.
3.Study of the axial fan regulation varying its turning speed.
4.Measurement
of inherent-speed machine performance in terms static and total
pressure, rotor speed and motor input power, as an inlet flow function.
5.Introduction to similarity laws for scale-up.
6.Obtaining of the characteristic curves of an axial fan.
7.Calculation of the Flow on a Hole Plate..
8. Calculation of the Flow through a Symmetrical Seal. Test with an Outlet Duct and a Nozzle.
9.Calculation of the Fan Output.
10.Introduction to the Scaling Similitude Law.
11.Flow calculation through a measurement of the static, dynamic and total pressure..
12.Typical curve calculation of a fan with a constant turning speed depending on the flow used by the symmetrical seal. Fluid Mechanics Lab Equipments manufacturers.
