CAT NO: DIDACTICNLE-Export-205105
Exercises and Practical Possibilities to be done with Main Items
1.-Performance of a compressor.
2.-Demonstration of the phenomenon of air compression, after passage through the compressor impeller.
3.-Study of the variation of compressor performance with speed.
4.-Measurement of compressor efficiency and estimation of impeller power efficiency.
5.-Measurement
of constant-speed machine performance in terms of static and total
pressures, rotor speed and motor shaft power, as a function of inlet
flow.
6.-Introduction to similarity laws for scale-up.
7.-Measurement of performance at constant speeds.
8.-Compressor curve for different stages.
9.-Calculation of the flow by means of the orifice plate.
10.-Calculation
of the characteristic curve of a centrifugal compressor at a constant
turn speed according to the flow used by the symmetrical stopper.
11.-Study and comparison of the computer results with the students calculations.
Additional practical possibilities:
12.-Sensors calibration.
Other possibilities to be done with this Unit:
13.-Many students view results simultaneously.
To view all results in real time in the classroom by means of a projector or an electronic blackboard.
14.-Open Control, Multicontrol and Real Time Control.
This
unit allows intrinsically and/or extrinsically to change the span,
gains; proportional, integral, derivate parameters; etc in real time.
15.-The Computer Control System with SCADA allows a real industrial simulation.
16.-This unit is totally safe as uses mechanical, electrical and electronic, and software safety devices.
17.-This unit can be used for doing applied research.
18.-This unit can be used for giving training courses to Industries even to other Technical Education Institutions.
19.-Control of the HCCC unit process through the control interface box without the computer.
20.-Visualization of all the sensors values used in the HCCC unit process.
- By using PLC-PI additional 19 more exercises can be done.
- Several other exercises can be done and designed by the user. Fluid Mechanics Lab Equipments manufacturers.
