CAT NO: DIDACTICNLE-Export-205108
EXERCISES AND PRACTICAL POSSIBILITIES
Some Practical Possibilities of the Unit:
1.- To determine the operating characteristics of a Kaplan turbine at different velocities.
2.- Determination of the typical turbine curves.
3.- Turbine power output versus speed and flow rate at various heads.
4.- Effect of guide vane setting on turbine performance.
5.- Flow calculation.
6.- Adimensional analysis.
7.- Investigation of the conversion of hydraulic energy into mechanical energy.
8.- Determining the hydraulic turbine efficiency.
9.- Calculating the turbine power.
10.- Determining the hydraulic turbine efficienciy.
Other possible practices:
11.- Sensors calibration.
Practices to be done by PLC Module (PLC-PI)+PLC Control Software:
12.- Control of the TKC unit process through the control interface box without the computer.
13.- Visualization of all the sensors values used in the TKC unit process.
14.- Calibration of all sensors included in the TKC unit process.
15.- Hand on of all the actuators involved in the TKC unit process.
16.-
Realization of different experiments, in automatic way, without having
in front the unit. (This experiment can be decided previously)
17.-
Simulation of outside actions, in the cases do not exist hardware
elements. (Example: test of complementary tanks, complementary
industrial environment to the process to be studied, etc)
18.- PLC hardware general use and manipulation.
19.- PLC process application for TKC unit.
20.- PLC structure.
21.- PLC inputs and outputs configuration.
22.- PLC configuration possibilities.
23.- PLC program languages.
24.- PLC different programming standard languages (literal structured, graphic, etc.).
25.- New configuration and development of new process.
26.- Hand on an established process.
27.- To visualize and see the results and to make comparisons with the TKC unit process.
28.- Possibility of creating new process in relation with the TKC unit.
29.- PLC Programming Exercises.
30.- Own PLC applications in accordance with teacher and student requirements. Fluid Mechanics Lab Equipments manufacturers.
