Linear IC Tester For Electrical Lab Training

Linear IC Tester For Electrical Lab Training

CAT NO: DIDACTICNLE-Export-083004

Linear IC Tester For Electrical Lab Training Description and Tender Specification:

Linear IC Tester For Electrical Lab Training.
It is the latest microprocessor controlled linear IC functional tester. It functionally test a variety of linear ICs including commonly used operational amplifiers, comparators, transistor arrays, optocouplers, analog switches, multiplexers, voltage followers, timers, A to D converters, D to A converters, cross point switches and other selected special function analog ICs.   Features: No personality cards/reference IC/IC data required. Automatic testing of IC after entering the IC number. No wiring is required. Continuous mode of testing ICs until Aborted. Number of times the test was successful id displayed. Buzzer to indicate bad IC Separate field for display of mode of operation (One/Con/Stp). Backspace, clear, select option and number keys for editing IC number. Remembers the IC number for repeated testing of same IC Self Test facility during Power ON and through keyboard Help key for short description of the various key functions Potential free 20 pin (ZIF Insertion Force) socket for easy insertion and removal of IC under test Computer interface through  for enhancement of IC test library   Technical Specifications: Package  Linear ICs and Analog & digital combined ICs of 6 , 8, 10, 14, 16, 18,   20, pins dual in line. (Also round pack if inserted after bending leads to suit DIP) Range    - Operational amplifiers, Comparators, Transistor arrays, Optocouplers, Analog switches, Multiplexers, Voltage Followers, Timers, A to D converters, D to A converters and other selected special function analog ICs, Method     -  Output test with simulated inputs and at nominal loads. It performs  only functional test and not parameter test. Socket       -  20 pin DIP ZIF Keyboard   - 24 feather touch keys Display      - 16 character LCD dot matrix display Voltage 230V ± 10% 50Hz AC Enclosure   - Sheet metal box with powder coating and screen printing Dimensions - 25 x 24 x 6cm Weight        - 3.5 Kgs. Appr.
