8 Directional Vertical Milling- Engineering Lab Training Systems

8 Directional Vertical Milling- Engineering Lab Training Systems

CAT NO: DIDACTICNLE-Export-136002

Description & Specification:

8 Directional Vertical Milling- Engineering Lab Training Systems.
Specifications: - Max clearance, table to spindle : 229mm - Throat : Adjustable. - Travel: “X” Axis: 229 mm “Y” Axis: 178 mm “Z” Axis: 137 mm - Hole through spindle: 10 mm - Spindle nose thread : 3/4 -16 T.P.I - Spindle taper : #1 Morse - Table Size : 70 x 330 mm - Hold down provision: 2 “T” Slots. - Motor : 90 Volt DC with electronics speed control automatically converts any input from 100 VAC to 240 VAC, 50 or 60 Hz. - Spindle speed range: 70-2800 RPM continuously variable by electronic speed control.
