CNC Micro Mill- Engineering Lab Training Systems

CAT NO: DIDACTICNLE-Export-136001

Description & Specification:

CNC Micro Mill- Engineering Lab Training Systems.
This desktop machining system has capabilities to produce most anything from very simple to very complex geometric forms in wood, plastic, aluminum or steel. Machine Features : - Stepping Resolution: 0.03mm - Mechanical Repeatability: 0.01mm - Spindle Speed 1100-11000 RPM - Travel: X=300mm, Y=146mm, Z=153mm - Rapid Travel of 30 in/min. - Universal Standard G-Code Import. - Precision Mechanics. - Box way Z-axis assembly with ground steel plate and tapered brass gib. - Adjustable tapered brass gib on X-axis. - Ground steel sliding ways with adjustable brass gib. - Hard anodized aluminum table - ½ “ (12.7 mm) 20 pitch Cr-Mo lead screws.
