CAT NO: DIDACTICNLE-Export-136005
CNC Lathe System- Engineering Lab Training Systems.
Specifications: - Swing over bed: 90 mm - Swing over carriage: 45 mm - Distance between centers: 430 mm - Hole through spindle: 10mm - Spindle nose thread: ¾”-16 T.P.I. - Spindle nose taper: #1 Morse - Travel of crosslide: 110 mm - Taper of tailstock spindle: #0 Morse. - Travel of crossable: 110 mm - Taper of tailstock spindle: #0 Morse - Protractor Graduations: 0 deg to 45 deg by 5 deg - Handwheel graduations: 0.01 mm - Motor: 90 Volt DC, input: 220 VAC, 50 Hz - Spindle speed range motor holding torque: 136 oz-in. - Rapid travel speed: X and Z: 22 inches/min
